Folio Base - Base 1 / Base 1 + Viti

Base 1 -> Rectangular luminaire with 9mm thickness for flat surface installation. Guaranteed light homogeneity thanks to the laser-engraved methacrylate plate with Folio® Edge Lighting technology. Body in aluminium. Customizable in size, shape and thickness. The two components are not fixed to each other (if the panel is rotated by 180° the "source" plate can come out of the body) and for this reason it is possible to install the Base 1 panel only on flat surfaces.

Base 1 + Viti -> Rectangular luminaire with 9mm thickness available for multiple mounting options. Guaranteed light homogeneity thanks to the laser-engraved methacrylate plate with Folio® Edge Lighting technology. Body in aluminium. Customizable in size, shape and thickness.  The two components are fixed together with micro-screws placed on the rear perimeter of the panel; the tips of the screws are visible on the bright side of the panel.

Brand: Folio

  • ·Specifications
  • ·Features
  • ·Dimensions

·Specifications

Base 1

Lamp: LED MODULE

Wattage: 22W / 25W

Lumen: 2000lm / 2200lm

Color Temp. [K] 2700, 3000, 3500, 4000, 5700



Base 1 + Viti

Lamp: LED MODULE

Wattage: 22W / 25W

Lumen: 2000lm / 2200lm

Color Temp. [K] 2700, 3000, 3500, 4000, 5700

·Features

Dimmability: 0-10V/ 1-10V/ DALI/ DMX/ Bluetooth/ PUSH

Aluminum finishes: Ox silver / white / black



·Dimensions

Base 1 Thickness: 9 mm | 0.36 in

Weight: 11 kg/m² | 2.3 lbs/ft²



Base 1 + Viti

Thickness: 9 mm | 0.36 in

Weight: 11 kg/m² | 2.3 lbs/ft²
